Coverings

Raised Access Flooring Accessories


Resflor offers customers a wide range of raised access flooring accessories to ensure the proper functioning of the raised access flooring technology. All Resflor accessories are compatible with our raised access flooring systems as well as other raised access flooring brands in the market.

Affiliated Category: Coverings

Transparent Glass Panel

The glass panel is made of specially crafted glass embedded in steel or aluminum frames with a size of 600*600 mm. It is compatible with the whole range of Resflor raised floor system by using a uniquely designed strong steel or aluminum frame. Mostly used in computer room, equipment room, data center and so on.

For Steel Cementitious

For Steel Cementitious

For Calcium Sulphate / Woodcore

For Calcium Sulphate / Woodcore


Air Booster

It is composed of ventilation grille, air supply fan and temperature control system. It is a special equipment for cooling dispatch in data center.

The small-scale axial-flow fan startup technology is adopted, energy-saving and stable, and an automatic temperature control system is built in. According to the temperature sensor, the exhaust temperature of the server is sensed, and the air supply volume is automatically controlled to ensure the cooling requirement of the server.

The ventilation rate of the ventilated grille floor reaches 75%, the single floor load reaches 600 kg, the ultra-thin design, the overall thickness is 100 mm, suitable for the lowest 200mm overhead floor room.

Air Booster

Air Booster

Performance

Model Heat Load Size Max.Air Volume Loading Capacity Max.Power
ADU2600 12 KW 600x600x200mm 2120 CFM 1200 Kg/m2 180W
ADU4600 22 KW 600x600x200mm 2825 CFM 1200 Kg/m2 320W

All models can be equipped with Fire Linkage Template.


Panel Lifter

A panel lifter is a tool designed to lift and move various types of panels, such as wood panels, glass sheets, and plastic panels, making it easier and more ergonomic for operators to handle heavy and bulky materials.

It comes in different types and designs, including vacuum panel lifters with customizable suction cups and ergonomic handles for precise control, as well as mechanical panel lifters with structures like toggle linkages or eccentrically mounted spindles.

Panel lifters improve work efficiency, reduce the risk of injury, and ensure the safe and damage-free handling of panels during installation or removal processes.

PJ-XP-1

PJ-XP-1

• 125mm diameter vacuum suction cup. • 100mm height. • Recommended lifting capacity is 15kgs.
PJ-XP-2

PJ-XP-2

• 110mm diameter vacuum suction cup. • 250mm length. • 140mm height. • Recommended lifting capacity is 30kgs.
PJ-XP-3

PJ-XP-3

• 120mm diameter vacuum suction cup. • 90mm height. • Recommended lifting capacity is 50kgs.

Floor Boxes

Resflor floor boxes are designed to work in concrete and raised access flooring applications. We provide various options of data, voice and audio - video outlet provisions, allowing complete distribution of telecommunication and data communication requirements along with power outlets from one point. Which is helpful for your cable and wire management needs through the openings in the cover. A single box can be specified for multiple floor types without having to order additional components or accessories.

PJ-DC-X1

PJ-DC-X1

Cover size: 340mm x 240mm Body size: 320mm x 220mm
PJ-DC-X2

PJ-DC-X2

Cover size: 250mm x 140mm Body size: 235mm x 112mm
PJ-DC-X3

PJ-DC-X3

Cover size: 250mm x 220mm Body size: 235mm x 200mm
PJ-DC-X4

PJ-DC-X4

Cover size: 250mm x 220mm Body size: 230mm x 210mm
PJ-DC-X5

PJ-DC-X5

Cover size: 250mm x 220mm Body size: 220mm x 200mm

Brush Grommets

Brush grommets are mainly used for wire management and sealing. They create a seal around the space where cables pass through, preventing unwanted airflow leakage and helping to maintain temperature and keep the workspace tidy and safe.

Brush grommets come in different types and sizes, including single or double brush holders, and various materials and configurations to meet different installation and usage requirements.

PJ-MS-X1

PJ-MS-X1

Cover size: Φ145mm Body size: Φ100mm Open size: Φ105mm
PJ-MS-X2

PJ-MS-X2

Cover size: 175mm x 175mm Body size: 135mm x 135mm Open size: 140mm x 140mm
PJ-MS-X3

PJ-MS-X3

Cover size: 190mm x 190mm Body size: 140mm x 140mm Open size: 145mm x 145mm
PJ-MS-X4

PJ-MS-X4

Cover size: 285mm x 215mm Body size: 235mm x 165mm Open size: 240mm x 170mm

Grommets

Floor grommets are essential components for cable management in flooring systems.   They provide a safe and organized way to run cables underneath the floor, protecting them from damage and reducing tripping hazards.

These grommets come in various sizes, colors, and materials, and are often made of durable ABS plastic.   They usually feature a rotating cover that closes snugly around cables to prevent debris and objects from getting caught.

Floor grommets are widely used in different settings like classrooms, data closets, and call centers, improving the aesthetics of the space by hiding unsightly cables and wires, while also maintaining a clean and professional appearance.

PJ-CXH-1

PJ-CXH-1

Cover size: Φ138mm Body size: Φ125mm
PJ-CXH-2

PJ-CXH-2

Cover size: 155mm*260mm Body size: 155mm*115mm
PJ-CXH-3

PJ-CXH-3

Cover size: 137mm*137mm Body size: 120mm*120mm

Line Laser Level

A line laser level is a tool that projects a level laser line, which is extremely useful for creating straight lines and ensuring accurate leveling in various construction and DIY tasks.

Line Laser Level

Line Laser Level


Cutting Saw

The cutting saw is a hand-held tool used for cutting raised access floor panels like steel cementitious, calcium sulphate, woodcore/chipboard and aluminum-alloy types.

Manual Cutting Saw

Manual Cutting Saw


Bandsaw

Bandsaws are professionally used for wood and metal cutting and adopts a vertical structure. It offers advantages like uniform cutting action due to evenly distributed tooth load and the ability to cut irregular or curved shapes.

Bandsaw

Bandsaw


Smart Air Diffuser

Smart air diffusers are used in elevated floor air supply systems. The product uses a sandwich floor air supply method and is mainly suitable for occasions where it is necessary to strengthen the existing air convection in the personnel stay area. Air convection or air rise may be caused by indoor personnel, machines or electrical equipment. Indoors where computers and other electronic equipment are used, more and more air is supplied from the floor upwards. This airflow form can quickly eliminate local heat loads in a targeted manner.

Smart Air Diffuser

Smart Air Diffuser


Ventilation Air Grille

A ventilation air grille is a type of covering or grating, made of metal , that is installed in floors to allow the flow of air in and out of a space, facilitating proper ventilation. It comes in various shapes, sizes, and designs, such as square, rectangular, or circular, and can have adjustable blades or louvers to control the direction and volume of the air passing through.

Ventilation Air Grille Top

Ventilation Air Grille Top

Ventilation Air Grille Bottom

Ventilation Air Grille Bottom


Skirting & Connection Strip & Cove Former

Resflor provide all kinds of skirting, connection strip and cove former. Material: SPC, WPC, PVC, wooden and aluminum-alloy.

Skirting & Connection Strip & Cove Former

Skirting & Connection Strip & Cove Former


Wooden Wedge (Shimming Kit)

Wooden wedge is made of wood and has a tapered shape that allows it to be easily inserted into the gap between concrete slab and raised access floor pedestal base plate to level pedestal with wedges.

Wooden Wedge

Wooden Wedge

Wooden Wedge

Wooden Wedge


Aluminum Foil Tape

Resflor panel edge sealing aluminum foil is a specialized material used to cover and protect the edges of flooring. It is made of aluminum foil with an adhesive backing, providing a durable and moisture-resistant seal.

This type of aluminum foil is designed to enhance the appearance of the floor by creating a smooth and finished edge. It also helps to prevent damage from moisture, dirt, and wear, prolonging the lifespan of the flooring.

Aluminum Foil Tape

Aluminum Foil Tape

Aluminum Foil Tape

Aluminum Foil Tape


Self-adhesive Aluminum Pad

Resflor self-adhesive aluminum pad is a specialized material used under the rubberized sound deadening gasket cap for pedestal top plate to level and adjust raised access floor panel tolerances. It is made of aluminum with an adhesive backing.

Self-adhesive Aluminum Pad

Self-adhesive Aluminum Pad

Self-adhesive Aluminum Pad

Self-adhesive Aluminum Pad


Foam Strip

Resflor foam tape is a special type of foam tape with EVA foam as the base material, it's used to affix the raised access floor panel's edges. With the advantages of water resistance, anti-vibration, thermal insulation, sound insulation, high viscosity, and easy peeling.

Foam Strip

Foam Strip

Foam Strip

Foam Strip

Why Resflor Be Trusted By 200+ Clients All Over the World?

Large Scale Production Capacity

Large Scale Production Capacity

Resflor monthly production capacity is 2.7 million sq.ft raised access floorings.

20+ Years’ Experience of Manufacturing and Exporting

20+ Years’ Experience of Manufacturing and Exporting

We have 20+ years’ experiences in manufacturing and exporting, our products has been exported 100+ countries.

Hundreds of International Project Experience

Hundreds of International Project Experience

Over the past ten years, we have supported hundreds of high-quality projects around the world.

Strict Quality Control

Strict Quality Control

Precisely follow quality management system, win customers and market with high quality advantage.

Focus on R&D&I

Focus on R&D&I

Whether you have your own design or specific requirements, Resflor is capable of guaranteeing the desired results from the design to the final production.

Sustainable Responsibility

Sustainable Responsibility

Resflor raised access flooring is also a powerful instrument in the push for greater sustainability and efficiency in our built environment.

Contact Resflor

Our Plants and Facilities

Steel Cementitious Production

Steel Cementitious Production

Steel Cementitious Production

Steel Cementitious Production

Steel Cementitious Production

Steel Cementitious Production

Steel Cementitious Production

Steel Cementitious Production

Steel Cementitious Production

Steel Cementitious Production

Steel Cementitious Production

Steel Cementitious Production

Steel Cementitious Production

Steel Cementitious Production

Steel Cementitious Production

Steel Cementitious Production

Steel Cementitious Production

Calcium Sulphate/Woodcore Production

Calcium Sulphate/Woodcore Production
Calcium Sulphate/Woodcore Production
Calcium Sulphate/Woodcore Production
Calcium Sulphate/Woodcore Production
Calcium Sulphate/Woodcore Production
Calcium Sulphate/Woodcore Production
Calcium Sulphate/Woodcore Production
Calcium Sulphate/Woodcore Production

Lamination Line

Lamination Line
Lamination Line
Lamination Line

Warehouse

Warehouse
Warehouse
Warehouse
Warehouse
Warehouse
Warehouse
Warehouse
Warehouse

Packing

Packing

Pedestals and Stringers

图片名称
图片名称
图片名称
